Raw Materials
Phillips countersunk machine screws can be produced from a variety of materials to suit different working environments:
Carbon Steel (C1022 / C1018)
For general industrial applications
Alloy Steel
For higher strength requirements
Stainless Steel (SS304 / A2, SS316 / A4)
For corrosion-resistant environments
Brass
For electrical and decorative applications
Surface finishes may include zinc plated, black oxide, nickel plated, phosphate, or plain stainless steel finish.
Size Chart (Metric Standard – DIN 965)
| Thread Size | Head Diameter (mm) | Head Height (mm) | Phillips Drive |
|---|---|---|---|
| M2 | 4.0 | 1.2 | PH1 |
| M3 | 6.0 | 1.7 | PH2 |
| M4 | 8.0 | 2.3 | PH2 |
| M5 | 10.0 | 2.8 | PH3 |
| M6 | 12.0 | 3.3 | PH3 |
Technical Data Chart
| Property | Specification |
|---|---|
| Head Angle | 90° |
| Drive Type | Phillips (PH) |
| Thread Type | Metric / Inch |
| Standard | DIN 965 / GB/T 819 / ASME B18.6.3 |
| Tensile Strength | Up to 800 MPa (carbon steel) |
| Hardness | As per customer requirement |
| Manufacturing Process | Cold Heading + Thread Rolling |
Phillips Countersunk Flat Head Machine Screw DIN965
Phillips countersunk machine screws are designed for applications requiring a flush surface finish. The flat head allows the screw to sit level with or below the surface, making it ideal for precision assembly.
Specifications
Standard: DIN965 / ISO7046
Drive Type: Phillips
Head Type: Countersunk flat head
Size Range: M2 – M12
Material: Carbon Steel / Stainless Steel
Finish: Zinc plated, black oxide, nickel plated
Features
✔ Flush installation for clean appearance
✔ Easy tightening with Phillips drive
✔ High precision threading
✔ Suitable for thin materials
Applications
Electronics assembly
Furniture manufacturing
Sheet metal fastening
Electrical components
Why Choose Us
Stable production quality
Wide size availability
OEM & custom packaging
Fast delivery for bulk orders
Inquiry Now
Looking for reliable machine screw supplier?
Send your RFQ today.
